RE66

Image 1
  • Image 1
Availability:
For general enquiries please contact us
Bookmark and Share

Description

ce.jpgemc-lvd.jpgrohs.bmpiec61010.jpg cat-ii-600.jpg auto-power-off.jpg

Features

  • 4000 counts LCD Display
  • Analogue Bar Graph
  • Auto Range & Manual Range
  • DC / AC Voltage
  • DC / AC Current
  • Resistance
  • Diode Test
  • Audible Continuity Test
  • Transistor hFE Test
  • Capacitance
  • Frequency
  • Data Hold
  • MAX / MIN Function
  • Relative Measurement
  • Auto Power Off
  • Low Battery Indication
  • Overload Protection
  • Product Size: 189 x 91 x 32 mm
  • Product Net Weight: 310g

Specification

Specifications Range Best Accuracy
DC Voltage 400mV/4V/40V/400V ±(0.5%+2)
600V ±(0.8%+2)
AC Voltage 400mV/4V/40V/400V ±(0.8%+3)
600V ±(1.2%+2)
Resistance 400Ω ±(1.0%+1Ω)
4KΩ/40KΩ/400KΩ/4MΩ ±(1.0%+2)
40MΩ ±(1.5%+3)
DC Current 4mA/40mA/400mA ±(1.2%+2)
4A/10A ±(2.0%+3)
AC Current 4mA/40mA/400mA ±(1.5%+3)
4A/10A ±(2.5%+5)
Capacitance　  4nF/40nF ±(3.0%+10)
400nF/4µF ±(2.5%+5)
40µF ±(5.0%+10)
Frequency 10Hz/100Hz/1KHz/10KHz/ ±(0.1%+5)
100KHz/600KHz

Supplied Accessories
