Description

ce.jpgemc-lvd.jpgrohs.bmpiec61010.jpg cat-ii-1000.jpg cat-iii-600.png auto-power-off.jpg

Features

  • 4000 counts LCD Display
  • Auto Range & Manual Range
  • DC/AC Voltage
  • DC/AC Current
  • Resistance
  • Diode Test
  • Audible Continuity Test
  • Transistor hFE Test
  • Capacitance
  • Frequency
  • Inductance
  • Duty Cycle
  • Data Hold
  • Relative Measurement
  • Auto Power Off
  • Low Battery Indication
  • Overload Protection
  • Produc Size: 189 x 91 x 32 mm
  • Product Net Weight: 310g

    • Specification

    Specifications Range Best Accuracy
    DC Voltage 400mV ±(0.8%+3)
    4V/40V/400V ±(0.8%+1)
    1000V ±(1.0%+3)
    AC Voltage 4V/40V/400V ±(1.0%+5)
    750V ±(1.2%+5)
    Resistance 400Ω ±(1.2%+2)
    4KΩ/40KΩ/400KΩ ±(1.0%+2)
    4MΩ ±(1.2%+2)
    40MΩ ±(1.5%+2)
    DC Current 400μA/4000μA ±(1.0%+2)
    40mA/400mA ±(1.2%+3)
    4A/10A ±(1.5%+3)
    AC Current 400μA/4000μA ±(1.5%+5)
    40mA/400mA ±(2.0%+5)
    4A/10A ±(1.5%+3)
    Capacitance 4nF ±(5.0%+10)
    40nF/400nF/4µF/40µF ±(3.5%+5)
    100µF ±(4.0%+1)
    Frequency 10Hz/100Hz/1KHz/10KHz/ ±(0.1%+5)
    100KHz/1MHz/10MHz
    Inductance 4mH/40mH/400mH/4H ±(3.5%+5)

    Supplied Accessories
